Allen-Bradley Stratix 5700 12 Port 1783-HMS8T4CGN Yönetilebilir Siviç

Port Yapısı:

-8 × Fast Ethernet RJ 45 (10/100 Mbps) Copper
-4 × combo port (10/100/1000 Mbit copper yada Fiber seçenekli)

Güç & Tüketim:

-Giriş voltajı: 3.7 A max @ 12…54V DC
-Maks. güç tüketimi: 35 W @ 24V DC @ 40 ˚C (104 ˚F)

Çalışma Ortamı & Dayanıklılık:

-Sıcaklık aralığı: -40…+70 °C (-40…+158 °F)
-Şok direnci: 15 g (çalışma), 30 g (çalışmama)
-Ağırlık: 2.88 kg

Endüstriyel Ağ Özellikleri:

-Yönetilebilir switch: CIP Sync, Device Level Ring (DLR) x 3, MSTP, REP, Qos, VLAN, ACL, Nat
-Standard : IEC 61850-3
-EEE 1613
-UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584. UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. and Canada. See UL File E194810. UL Listed for Class I, Zone 2 Hazardous Locations, certified for U.S. and Canada. See UL File E194810. Ex nA nC IIC T3 Gc X AEx nA nC IIC T3 Gc
-European Union 94/9/EC ATEX Directive, compliant with: • EN 60079-0; General Requirements • EN 60079-15; Potentially Explosive Atmospheres, Protection "n" • II 3 G Ex nA nC IIC T3 Gc • DEMKO14ATEX1423X
-European Union 2004/108/EC EMC Directive, compliant with: • EN 61326-1; Meas./Control/Lab., Industrial Requirements • EN 61000-6-2; Industrial Immunity • EN 61000-6-4; Industrial Emissions • EN 61131-2; Programmable Controllers (Clause 8, Zone A & B) European Union 2011/65/EU RoHS, compliant with: • EN 50581; Technical Documentation

Montaj:

-DIN Ray veya panel montajı (kompakt form)
